EFM1 Gen2
The Evolve® LED Medium Output Flood Light is our mid-lumen solution to efficiently illuminate building facade, flag poles, billboard signage and many more traditional flood applications. Designed to replace from 150W – 400W HID flood light solutions.
Features:
- Easy Upgrade to LED
- Installs in Less Than 5 Mins.
- Reduce Power Consumption by 50%
- Durable Aluminum 1 Piece Kit
- 0-10V Dimmable Driver (100% – 10%)
- Frosted Acrylic, Clear Acrylic, Or Polycarbonate Lens Options
- ETL Listed
- 5 Yr. Warranty
- DesignLights Consortium® Premium Qualified Luminaire
Related products
Construction
Housing:
Aluminum die cast enclosure. Integral heat sink for maximum heat transfer
Lens:
Impact resistant tempered glass
Paint:
Corrosion resistant polyester powder paint, minimum 2.0 mil thickness Standard = Black, Dark Bronze, Gray, White (RAL & custom colors available) Optional = Coastal Finish
Weight:
25 lbs (11.34 kgs)
Lumen Maintenance
Projected Lxx per IES TM-21-11 at 25°C
LUMEN CODES
DISTRIBUTION
LXX(10K) @ HOURS
25,000 HR
50,000 HR
60,000 HR
10, 15
77, 76, 67, 66, 65
L99
L99
L99
20, 25
77, 76, 67, 66, 65
L99
L99
L99
30
77, 76, 67, 66, 65
L94
L87
L85
10
33
L97
L97
L97
15, 20
33
L97
L96
L96
25
33
L97
L96
L95
Note: Projected LXX based on LM80 (> 10,000 hour testing). Accepted Industry tolerances apply to initial luminous flux and lumen maintenance measurements.
Optical System
Lumens:
8,500 to 29,000
Distribution:
3x3, 6x5, 6x6, 7x6, 7x7
Efficacy:
16-165 LPW
CCT:
2700K, 3000K, 4000K, 5000K
CRI:
≥70
Luminaire Ambient Temperature Factor
Projected Lxx per IES TM-21-11 at 25°C
AMBIENT TEMP (°C)
INITIAL FLUX FACTOR
AMBIENT TEMP (°C)
INITIAL FLUX FACTOR
10
1.02
30
0.99
20
1.01
40
0.98
Note: Projected LXX based on LM80 (> 10,000 hour testing). Accepted Industry tolerances apply to initial luminous flux and lumen maintenance measurements.
Electrical
Input Voltage:
120-277V & 277-480V
Input Frequency:
50/60Hz
Power Factor:
≥ 90% at rated watts
Total Harmonic Distortion:
≤ 20% at rated watts
Ratings
Operating Temperature:
-40°C to 50°C*
Vibration^:
3G - Slipfitter Mounting K1, K2, S1 & S2 3G - Trunnion Mounting T1
LM-79:
Testing in accordance with IESNA Standards
*45°C for SKUs >168W at 120-277V with DALI (Option U) ^Per ANSI C136.31-2010
Surge Protection
TYPICAL
ENHANCED
EXTREME
6kV/3kA*
10kV/5kA*
20kV/10kA*
Controls
Dimming:
Standard - 0-10V Optional - DALI (Option U)
Sensors:
Photo Electric Sensors (PE) available LightGrid and Daintree Compatible
